Mittler Bros. Heavy-Duty Hydraulic Tube Notcher

Part #: 100-U-MB
Ships From: Our warehouse

Lead Time: Usually ships within 1 day

We want to give you the best information possible regarding your order at Trick-Tools and product availability is very important to us. This information reflects our best estimate of the shipping time for your order on a product by product basis. Items in stock at our warehouse typically ship same day if the order is placed before 3pm Central Time.

Availability on Items shipped directly from the factory is an estimate for that product based on averages from our experience. Items marked "Call for availability" have limited stock or unpredictable lead times and require a phone call to get a lead time estimate. We apologize but we are unable to guarantee lead times on factory-shipped items.

Price: $1,595.00

1-1/2 to 2-3/8 inch OD capacity
Includes your choice of one die
Produce a ready-to-weld notch every time
Requires hydraulic pump, sold separately

SHIPPING:

ORIGIN:

BRAND:

DESCRIPTION

The Mittler Brothers Heavy Duty Hydraulic Tubing Notchers are precision-machined units based on a punch and die design. After twenty years of shop-proven performance, they have become some of the finest hydraulic notchers available. They offer small production shops and racers a durable and truly affordable tool. Compact, self-contained, lightweight and portable. They can be used in a bench vice, fixed stand or stand with wheels, and are handy enough to take to your work or store out of the way. They produce a perfect, ready-to-weld notch every time and turn out a professional piece again and again.

The heavy duty hydraulic notcher also uses the ten-ton ram. With that much power it will notch tubing up to 2-3/8 inch and 2 inch Schedule 40 Pipe, and can even handle limited angles when necessary. This hard working tool can easily notch tubing as short as three inches. The punch and die can also be re-sharpened, eliminating the need to replace parts.

Other features include:

1-1/2 inch OD to 2-3/8 inch OD capacity, .164 inch wall thickness max
Includes your choice of one die
Notches 1-1/4 inch Pipe (1.66 inch OD), 1-1/2 inch Pipe (1.90 inch OD) or 2 inch Pipe (2.375 inch OD)
Produces straight and limited angle cuts
Can be driven by hand, air or electric hydraulic pumps (not included)

Warranty:

1 year manufacturer's warranty
