Ben Pearson Model 3012 Bender

Part #: 3012
Ships From: Factory shipped

Lead Time: Usually ships within 6-8 weeks

We want to give you the best information possible regarding your order at Trick-Tools and product availability is very important to us. This information reflects our best estimate of the shipping time for your order on a product by product basis. Items in stock at our warehouse typically ship same day if the order is placed before 3pm Central Time.

Availability on Items shipped directly from the factory is an estimate for that product based on averages from our experience. Items marked "Call for availability" have limited stock or unpredictable lead times and require a phone call to get a lead time estimate. We apologize but we are unable to guarantee lead times on factory-shipped items.

Price: $12,596.50
Sale Price: $11,966.68

Unique design for interference free bending
Auto-stop for repeatable bends
58,000 lbs of bending force

FREIGHT:

ORIGIN:

BRAND:

DESCRIPTION

Ben Pearson Model 3012 has a unique tool post design that allows you to make parts with no interference from the hydraulic cylinder. The 3012 offers a knee pedal control along with manual and automatic push buttons allowing for the operator to keep both hands on the part.

The Smart Automatic Mode features an adjustable return-to–home position control along with a precise, easy to read depth of bend gauge. This unique, time-saving feature increases efficiency by assuring fast and easy transitions between multiple bends. A 5 horsepower motor provides 58,000 lbs of bending force.

The included heavy duty end finishing attachment accommodates 1 to 3 inch tubing in the swager box and from 1-1/4 to 4 inch on the expander. With the bull’s-eye expanding system, you can dial in precise expansions every time.

Optional Super 110 Tooling Package Kit Includes:

5 inch Radius dies for 2, 2-1/4, 2-1/2 and 3 inch material
4 inch Radius dies for 2 and 2-1/4 inch material
3 inch Radius dies for 1-1/2 and 1-3/4 inch
Full back shoes for 1-1/2 through 3 inch material
Half shoes for 1-1/2 through 2-1/2 inch material
Clamping collets for 1-1/2 inch through 2-1/2 inch material
45/90 degree Flare Tool
1-3/4 to 2 inch Female Ball Die
2-1/4 to 2-1/2 inch Female Ball Die
1-1/2 to 2-1/2 inch Expanding Swage Dies
Arbors, Tips, and Expanders for 1-1/2 to 3 inch material
Extra O-rings

Warranty:

1 year manufacturer's warranty

SPECIFICATIONS

•Mild Steel Capacity (inches): 3
•Nominal PIPE Capacity: 1-1/2 inch schedule 40
•Square Mild Steel Capacity (inches): 2-1/2
•Minimum OD (inches): 3/4
•Bending Style: ram-style
•Min Center Line Radius (inches): 3
•Max Center Line Radius (inches): 5
•Motor: 5 hp, 220 volt
•Control Method: knee control
•Repeatability Control: auto-stop
•Maximum OD (inches): 3
