Bend-Tech Dragon Square Tube Cutting and Marking System

Part #: BT-Dragon-Square
Model: BTD-A148, BTD-A296
Ships From: Factory shipped

Lead Time: Usually ships within 4-6 weeks

We want to give you the best information possible regarding your order at Trick-Tools and product availability is very important to us. This information reflects our best estimate of the shipping time for your order on a product by product basis. Items in stock at our warehouse typically ship same day if the order is placed before 3pm Central Time.

Availability on Items shipped directly from the factory is an estimate for that product based on averages from our experience. Items marked "Call for availability" have limited stock or unpredictable lead times and require a phone call to get a lead time estimate. We apologize but we are unable to guarantee lead times on factory-shipped items.

Price: $16,900.00

NEW

Plasma cutting, notching, marking and engraving
Up to 4 inch square tubing
Includes Bend-Tech Industrial CAD software

FREIGHT:

ORIGIN:

BRAND:

We're sorry but this product is currently unavailable.

DESCRIPTION

The Bend-Tech Dragon is an affordable, complete solution for tube notching, cutting, and marking. This model is built specifically for square or rectangle tubing up to 4 inches. The Dragon is capable of taking a full length of tubing, cutting it to length, notching the end profile, making holes or slots as needed, and then marking any bend locations with rotation and degrees. Bend-Tech Dragon obtains all of the necessary information from Bend-Tech Industrial software automatically. Just add your plasma machine and computer!

Included with the Bend-Tech Dragon is two powerful software packages; Bend-Tech Industrial and Bend-Tech Dragon Software. Working side by side, these products will allow you to create 3D CAD designs from scratch or convert from SOLIDWORKS, AutoCAD, Inventor, PRO Engineer, etc. into a readable format for the machine. Dragon Software will automatically create your cutting, marking and etching paths directly from Bend-Tech Industrial and comes with a nesting ability to allow several parts on the same stock tube.

Key Features

12 foot or 21 foot bed lengths, unlimited working length with re-positioning
2 inch through chuck allows for re-positioning of longer material with built in laser pointer.
Works with up to 4 inch square or rectangle tubing
3 heads include plasma cutting, sharpie marker, and engraving
Automatic tool change
150 lb material capacity
